Specifications

Benefits And Features

Equipment

Total Power Range

Typical Electrical Output	9-10 kVA (7.2-8 kWe)
Rated Speed	1500 rpm

50 Hz Typical Electrical Output

Emission Standards

Disclaimer

Definitions

General

Combustion System	Indirect Injection
Rotation from Flywheel End	Anti-clockwise
Cooling System	Liquid
Aftertreatment	-
Typical Alternator Efficiency	86%
Switchable	No

Compact and flexible

When you need power and reliability in a compact application, you can trust the 400 Series EP engines to deliver. Our engineers have carefully designed every component to minimise space. This can come in particularly handy in higher regulated territories where you need to consider size and space for aftertreatment solutions. Some models in the series also offer the convenience of switching between engine speeds and electrical frequencies to match your application and territory perfectly.

Efficient, quiet and powerful

The pressure on end users to reduce the fuel consumption of their machinery favours the 3 cylinder 403. Its power density, durability, fuel efficiency and quiet operation set it apart from similar sized competitors' engines. The 403 range's quiet operation makes it an excellent option where noise is a concern, particularly if you're operating in urban areas.

Lower operating costs

The reliability of the 403 range, its uncomplicated indirect injection fuel system, ease of installation and warranty offering all combine to keep your ownership costs to a minimum. As the 400 Series is built on a common engine platform, you can also upgrade easily and affordably.

Air inlet system

Mounted air filter

Control system

12 volt Electronic Shut Off Solenoid (ESOS) energised to run

12 volt starter motor and 12 volt 15 amp alternator with DC output

Glow plug cold start aid and heater/starter switch

Oil pressure and coolant temperature switches

Cooling system

Thermostatically-controlled system with belt driven coolant pump and pusher fan

Mounted radiator

piping and guards

Flywheel and flywheel housing

Flywheel housing SAE 5 long

High inertia flywheel to SAE J620 Size 165.1 mm (6½ in) heavy

Fuel system

Mechanically governed cassette type fuel injection pump

Split element fuel filter

General

Front and rear engine mounting brackets

Oil system

Spin-on full flow lub oil filter

Wet steel sump with filler and dipstick

Emissions	Fuel Optimized
Engine series	400 Series
Territory	Fuel Optimized
Power	0-27 kWm

Electric Power Diesel Engine

403A-11G
