| Ground Clearance | 394 mm |
| Max. Slope | 30° |
| Model | Weichai WD12G240E26 |
| Rated Power | 62 kW |
| Blade Type | SU |
| Blade Capacity | 6.4m³ (U 7.5m³) |
| Blade Width | 3,720 mm (U 4,015 mm) |
| Blade Height | 1,511 mm (S 1,420 mm) |
| Max. Blade Digging Depth | 563 mm |
| Max. Blade Lift Ground Clearance | 1,140 mm |
| Max. Output Rimpull | 350 kN |
| Max. Digging Depth Of Ripper | 650 mm |
| Max. Clearance Under Tip | 640 mm |
| Type | Electronic control, Dual-path, Hydrostatic Drive |
| Travel Speed - F/R (Infinitely Variable Speed Control) | 0-11.5 km/hr |
| Steering & Brake | Hydrostatic Steering, Wet, Multiple-Disc Brakes |
| Min. Steering Radius (Counter-rotated available) | 4,225 mm |
| Track Shoe Width | 560 mm |
| Track Shoe Quantity | 40 piece |
| Length Of Track On Ground | 2,948 mm |
| Track Guage | 2,000 mm |
| Track Roller Quantity | 7/side |
| Carrier Roller Quantity | 2/side |
| Type | Pilot Control |
| Implement Hydraulic System Pressure | 19 Mpa |
| Cooling System | 45 L |
| Hydrostatic Oil | 62 L |
| Implement Oil | 110 L |
| Fuel | 460 L |
| Pivot Shaft Case (each side) | 0.8 L |
